Drager
Oxylog 1000
10000419
Dräger Oxylog 1000
Versatile for Emergency Situations
The Dräger Oxylog 1000 is designed for demanding emergency environments, providing reliable ventilation support in mobile and stationary settings. Its user-friendly interface and compact design enable quick and effective patient care in critical situations.
Integrated Pressure and Volume Control
The Oxylog 1000 ventilator features automatic adjustments for controlling airway pressure and volume. This ensures safe and consistent ventilation for patients in critical conditions, optimizing medical response.
Portable Design
Data Handling
The Oxylog 1000 supports ventilation data documentation, which can be used to optimize patient care and follow-up.
Category | Attribute | Value |
---|---|---|
Dimensions | Height | 3.5 in (9 cm) |
Width | 8.27 in (21 cm) | |
Depth | 8.27 in (21 cm) | |
Weight | 3 kg | |
Measured values | Power supply | 20 W |
Breathing frequency | 60 /min | |
Ventilation modes | CMV, IPPV | |
Inspiratory pressure | 0-6 mbar | |
Tidal volume | 0-2000 ml | |
Airway pressure range | 0-60 mbar | |
PEEP | 0-10 mbar | |
Flowrate | 60 l/min | |
Oxygen-concentration | 60-100 % | |
Apnoe-return mode | Yes | |
Computed values | Compliance | 0-1 ml/mbar |
Resistance | 0-6 mbar/l/s |
